DIN series 43703, 1-25 amps 60mV shunt , Class 0,5%, with insulating base



  • Compliant with DIN 43703

  • Available in ratings from 1 amp to 25 amps

  • Class 0,5%

  • Voltage drop 60mV

  • Available in 50mV, 75mV, 80mv etc.

  • If our standard product does not meet your needs, please call

Screws

4 flat washers ZNB UNI 6592 Ø 5

4 studs TC Comby M5x8 Zinc.
